Resin Non Asbestos 20 Meters/Roll Woven Brake Lining

Resin Non Asbestos 20 Meters/Roll Woven Brake Lining
Resin Non Asbestos 20 Meters/Roll Woven Brake Lining

Large Image :  Resin Non Asbestos 20 Meters/Roll Woven Brake Lining

Product Details:

Place of Origin: CHINA
Brand Name: DALU
Certification: GB/T 19001-2016/ISO 9001:2015
Model Number: BXS-M

Payment & Shipping Terms:

Minimum Order Quantity: 0.5 Tons
Price: Negotiable
Packaging Details: exporting wooden case
Delivery Time: 6 weeks after down payment
Payment Terms: T/T
Supply Ability: 20 Tons
Detailed Product Description
Product Name: Non Asbestos 20 Meters/Woven Brake Lining Product Color: Brown
Application: Winch And Windlass Brake, Hoist Brake, Crane Brake, Winder Brake, Drilling Machine Brake Size: 10, 15, 20 Meters/roll
Material: Brass Wire, Resin, Viscose, Type: BXS-M
Woven: Woven Brake Lining Asbestos Free Woven Brake Lining Rolls Resin: Melamine Resin
Main Raw Material: Non-asbestos Yarns Color: Yellow
High Light:

20 Meters/Roll Woven Brake Lining

,

Hoist Non Asbestos Brake Lining

,

Windlass Resin Woven Brake Lining

Non Asbestos Woven Brake Lining yellow anchor brake lining Brake Lining in Roll woven brake lining



Non asbestos Woven Brake Lining ship anchor brake lining, winch brake lining,windlass brake lining lining,asbestos free



Woven Brake Lining Description:



Non-asbestos Woven Brake Lining selects new-type abrasion resistant and high temperature resistant non-asbestos yarns which contain brass wires, viscose fiber, Glass fiber, Aramid fiber etc.



Our product owns high performance of wear resistance, low wear rate, high tensile strength, good softness, high temperature resistance, corrosion resistance, oil resistance, long service life and impact resistance etc. They are definitely 100% non-toxic, pollution free and environmental products.



Brake Lining is extensively used in marine and industrial applications. It is suitable for winch and windlass, hoist, crane, winder, drilling and workover rigs, agricultural vehicle, elevator, and construction machinery.





Woven Brake Lining Specifications:



Temperature Coefficient of friction(μ) Wear rate(v)(cm³/N.m)
100℃ 0.35~0.65 ≤0.7 x 10-7
150℃ 0.35~0.65 ≤1.1 x 10-7
200℃ 0.30~0.60 ≤1.5 x 10-7
250℃ 0.25~0.60

≤2.5 x 10-7




Woven Brake Lining Features
1. Hot- Resistence
2. Long-Time Using
3. High Quality
4,Wear-Resistant ,Low-Noise,Less-Dust
5,Safe And Reliable.
6,Competitive Pricing And Quality Assured Products
7,Using Life Of Brake Lining :40000km



Ningbo Xinyan is a professional manufacturer of Non-asbestos friction material in China. More than 80% of our products have been exported to European and American markets.



Resin Non Asbestos 20 Meters/Roll Woven Brake Lining 0





Resin Non Asbestos 20 Meters/Roll Woven Brake Lining 1

Quick Detail:



Model: BXS-M Non-asbestos Woven Brake Lining

Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires, Melamine resin.

Working Conditions: 250℃,Static Pressure: 4.0Mpa

Applied field: It is widely used for braking deceleration and transmitting power of big power machineries.

Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m
