10m/Roll Melamine Resin Dock Crane Windlass Brake Lining

Place of Origin CHINA
Brand Name DALU
Certification GB/T 19001-2016/ISO 9001:2015
Model Number BXS-M
Minimum Order Quantity 0.5 Tons
Price Negotiable
Packaging Details exporting wooden case
Delivery Time 6 weeks after down payment
Payment Terms T/T
Supply Ability 20 Tons
Product Details
Product Name Non-asbestos Woven Brake Lining Ship Winch Brake Melamine Resin Brass Wire Dock Crane Product Color Brown
Application Winch And Windlass Brake, Hoist Brake, Crane Brake, Winder Brake, Drilling Machine Brake Size 10, 15, 20 Meters/roll
Material Brass Wire, Resin, Viscose, Type BXS-M
Woven Woven Brake Lining Asbestos Free Woven Brake Lining Rolls Resin Melamine Resin
Main Raw Material Non-asbestos Yarns Color Yellow
High Light

Dock Crane Windlass Brake Lining


Melamine Resin Windlass Brake Lining


10m/Roll Windlass Brake Lining

Leave a Message
Product Description

Non-asbestos Woven Brake Lining ship winch brake melamine resin brass wire dock crane


Ningbo Xinyan is a professional manufacturer of Non-asbestos friction material in China. More than 80% of our products have been exported to European, Asian,Africa, South American markets. As the leading manufacturer of woven brake lining in the world, we are stable and sustaining partner of the world famous winch maker.Relying on superior quality, strong technical power, excellent service, prompt delivery, We win good reputation and recognition from the domestic and abroad market, and has built long-term and friendly business relationship with the large state-owned enterprise and world famous companies. With comprehensive test equipment,Ningbo Xinyan is capable to offer the compared testing service and customized friction products.


Our advantage is that we also produce raw materials of non-asbestos yarns, then weave into brake lining by ourself, so that we have the whole cost and quality control.Our factory has 6 weaving machines and work with many customers around the world. I will make the quotation list for you after getting your detail size and qty. You could wechat/whatsapp me at (86) 13771895935 to get more informations.



Quick Detail:Non-asbestos Woven Brake Lining ship winch brake melamine resin brass wire dock crane


Model: BXS-M Non-asbestos Woven Brake Lining

Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires, Melamine resin.

Working Conditions: 250℃,Static Pressure: 4.0Mpa

Applied field: It is widely used for braking deceleration and transmitting power of big power machineries.

Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m

Color: Yellow


Description:Non-asbestos Woven Brake Lining ship winch brake melamine resin brass wire dock crane


Our product owns high performance of wear resistance, low wear rate, high tensile strength, good softness, high temperature resistance, corrosion resistance, oil resistance, long service life and impact resistance etc. They are definitely 100% non-toxic, pollution free and environmental products.




10m/Roll Melamine Resin Dock Crane Windlass Brake Lining 0




Specifications:Non-asbestos Woven Brake Lining ship winch brake melamine resin brass wire dock crane


Coefficient of friction(μ)

Wear rate(v)(cm³/N.m)



≤0.7 x 10-7



≤1.1 x 10-7



≤1.5 x 10-7



≤2.5 x 10-7


Non-asbestos Woven Brake Lining ship winch brake melamine resin brass wire dock crane

Applications:Woven Brake Lining is extensively used in marine and industrial applications. It is suitable for winch and windlass, hoist, crane, winder, drilling and workoverrigs, agricultural vehicle, elevator, industrial drum brakes, mining machinery and construction machinery. When it is supplied for use on oil immersed applications,the friction value will be much lower than it is used in dry conditions.
