Oil Resistant Asbestos Free Woven Mooring Winch Brake Lining
|Product Name||Non Asbestos Woven Brake Lining Roll Brass Wire Inserted Anchor Brake Moor Winch||Product Color||Brown|
|Application||Winch And Windlass Brake, Hoist Brake, Crane Brake, Winder Brake, Drilling Machine Brake||Size||10, 15, 20 Meters/roll|
|Material||Brass Wire, Resin, Viscose,||Type||BXS-M|
|Woven||Non Asbestos Woven Brake Lining Roll Brass Wire Inserted Anchor Brake Moor Winch||Resin||Melamine Resin|
|Main Raw Material||Non-asbestos Yarns||Color||Yellow|
Oil Resistant Mooring Winch Brake Lining,
Asbestos Free Mooring Winch Brake Lining,
Oil Resistant Woven Brake Lining
Non asbestos woven Brake Lining Roll Brass Wire inserted anchor brake moor winch
Quick Detail:Non asbestos woven Brake Lining Roll Brass Wire inserted anchor brake moor winch
Model: BXS-M Non-asbestos Woven Brake Lining
Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires, Melamine resin.
Working Conditions: 250℃,Static Pressure: 4.0Mpa
Applied field: It is widely used for braking deceleration and transmitting power of big power machineries.
Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m
|Temperature||Coefficient of friction(μ)||Wear rate(v)(cm³/N.m)|
|100℃||0.35~0.65||≤0.7 x 10-7|
|150℃||0.35~0.65||≤1.1 x 10-7|
|200℃||0.30~0.60||≤1.5 x 10-7|
|250℃||0.25~0.60||≤2.5 x 10-7|
Description:Non asbestos woven Brake Lining Roll Brass Wire inserted anchor brake moor winch
Non-asbestos Woven Brake Lining selects new-type abrasion resistant and high temperature resistant non-asbestos yarns which contain brass wires, viscose fiber, Glass fiber, Aramid fiber etc.
Our product owns high performance of wear resistance, low wear rate, high tensile strength, good softness, high temperature resistance, corrosion resistance, oil resistance, long service life and impact resistance etc. They are definitely 100% non-toxic, pollution free and environmental products.
We own advanced equipment, top technology and skillful workers which ensure the goods high quality. Our products have passed ISO9001:2000 international quality system certification and our factory has import-export operations right, which can make you save the cost on some extent. We are always playing great role in international market such as America, Europe and Southeast Asia etc.
Ningbo Xinyan Friction Materials Co., Ltd. warmly welcomes your visiting to our factory and we will offer you superior quality products and perfect service.
