Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake

Place of Origin CHINA
Brand Name DALU
Certification ISO9001,CTI
Model Number Non Asbestos Woven Brake Liner Mooring Winch Anchor Windlass Brake Lining Rolls
Minimum Order Quantity 0.5 Ton
Price Negotiated
Packaging Details Exporting Standard Pallet
Delivery Time 5-8 weeks after down payment
Payment Terms T/T, 30% Down Payment before production, 70% Balance paid before shipment
Supply Ability 20 tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake Thickness T(5~30)x W(≤500)mm
Material Viscose Fiber, Aramid Fiber, Glass Fiber, 2 Brass Wires, Asphalt Resin. Use Widely Used For Braking Deceleration And Transmitting Power Of Farm Machinery And Engineering Machinery.
Certification ISO9001,CTI
High Light

Mooring Brake Lining Non Asbestos

,

Mooring Non Asbestos Woven Brake Lining

,

CTI Non Asbestos Woven Brake Lining

Leave a Message
Product Description

Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake



Description:



Ningbo Xinyan Friction Materials Co., Ltd. is located in Simen Industrial Park by National Highway 329, with convenient transportation. The factory covers an area of 6,000 square meters, which is a comprehensive enterprise specializing in the production and sales of asbestos products, non-asbestos products, friction, sealing, anticorrosion, insulation and fire prevention materials.



We own advanced equipment, top technology and skillful workers in line with the "people-oriented, pragmatic and innovative" company concept, constantly using new technologies, new equipment, new materials, new process, and strive to do better, to develop more new friction, sealing, anti-corrosion, insulation, fire prevention materials to meet the needs of customers both domestic and abroad. Our products have passed ISO9001:2000 international quality system certification and our factory has import-export operations right, the product quality is in line with national standards based on a strict inspection process, and has been sold to more than 20 provinces and regions, more than a dozen countries and regions. The products have been selling well in the Americas, Europe and Southeast Asia, and are favored by domestic and foreign customers!

Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake 0Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake 1

Quick Detail:



Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake



Model: BXS-M Non-asbestos Woven Brake Lining

Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires, Melamine resin.

Working Conditions: 250℃,Static Pressure: 4.0Mpa

Applied field: It is widely used for braking deceleration and transmitting power of big power machineries.

Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m

Color: Yellow



Applications:



Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake



It is widely used for braking deceleration and transmitting power of big power machinery, such as ship winch, dock crane, drilling machinery, lifting machine, building machinery etc.



Specifications:

Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake

BXS-L

Temperature Coefficient of friction(μ) Wear rate(v)(cm³/N.m)
100℃ 0.30~0.60 ≤1.5 x 10-7
150℃ 0.25~0.60 ≤1.5 x 10-7



Competitive Advantage:



Our factory could produce the raw materials for brake lining. We have yarn machines, we produce yarns and then weeve yarns into brake lining rolls by ourself, so that we could control the whole quanlity and cost very well.



We adopted Japanese technical weaving machine and good technology to produce products, the brake lining quality is very good and the price is also very competitive, so that we have many customers in domestic and foreign market.



Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake



1, Professional Production, Quality Assurance, Affordable, All Factory Direct Sales.
2, Superior Material,we also produce raw materials of non-asbestos yarns, then weave into brake lining by ourself, so that we have the whole cost and quality control.

3, Fine Handcarft.
4, Competitive Price.
5, Good Service, Quality Assurance.

Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake 2Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake 3



Non Asbestos Woven Brake Lining Rolls Mooring Winch Anchor Windlass Brake 4
